ANYBEND BENDING MACHINE
Intelligent Sheet Metal Folding for Precision Manufacturing
Intelligent Sheet Metal Folding for Precision Manufacturing
Where Precision Becomes Productivity
Designed for modern sheet metal fabrication, our Bending Machine delivers ultra-precise, repeatable bends with high speed and minimal operator dependency. Using advanced servo-controlled bending technology, it replaces conventional press brake operations with intelligent, automated folding - ideal for panels, enclosures, cabinets, doors, and complex box-type components.
From small batch customization to high-volume production, the system ensures consistent quality, excellent edge straightness, and superior angular accuracy across carbon steel and similar materials.
PRODUCT
ANYBEND is an advanced CNC bending system designed to simplify complex sheet metal forming while delivering exceptional accuracy, speed, and repeatability. Built on servo-driven technology and intelligent motion control, ANYBEND eliminates the limitations of conventional press brakes and transforms the way panels and enclosures are manufactured.
SPECIFICATIONS
This bending solution is built for manufacturers who demand speed, consistency, and scalability.
| No. | Specification | Unit | B2516 | B3016 | B4016 | |
|---|---|---|---|---|---|---|
| 1. | Max. Bending Length | mm | 2440 | 2940 | 3940 | |
| 2. | Maximum Diagonal Sheet Length | mm | 2800 | 3500 | 4600 | |
| 3. | Min. Box Size | mm | 450×230 | |||
| 4. | Max. Bending Height | mm | 165 | |||
| 5. | Pressing Force | tonne | 50 (Max.110) | 75 | ||
| 6. | Max. Bending Inner Buckle Depth | mm | 30-50 | |||
| 7. | Thickness of Sheet | mm | 0.5-2.5 | |||
| (Carbon Steel) | ||||||
| 8. | Bending Angle | ° (degree) | －130 to＋130 | |||
| 9. | Bending Angle Accuracy | ° (degree) | ±0.75 | ±1 | ||
| 10. | Bend Straightness | mm/m | ±0.15 | ±0.2 | ||
| 11. | Positioning Accuracy | mm/m | ±0.05 | |||
| 12. | Adjustment of Bending Length | Auto | ||||
| 13. | Overlapping Function | √ | ||||
| 14. | Single Bending Time | s | ＜1.5（pressing-bending-lifting） | |||
| 15. | Axis | 18 | 20 | 23 | ||
| 16. | Gas Pressure | MPa (Megapascal) | ≥0.7 | |||
| 17. | Gas Consumption | L/min | 5 | |||
| 18. | Power Capacity, Three-phase Four-wire | KVA (Kilo-Volt-Amperes) | 35 | 35 | 45 | |
| 19. | Power Consumption | unit/hour | 4 | 5 | ||
| 20. | Weight | tonne | 20 | 22 | 33 | |
| 21. | Machine Dimensions | mm | 5000×3200×2950 | 5700×3700×2950 | 7900×5700×2950 | |
REASONS TO TRUST
✔ Eliminates manual bending variability
✔ Reduces setup time and operator skill dependency
✔ Ideal for box-type, multi-flange, and enclosure components
✔ Compact footprint with high production output
DEVELOPMENT
Every element of this bending system is developed to enhance production efficiency while maintaining micron-level precision:
The machine handles inward and outward bends seamlessly, even on compact parts, making it a powerful solution for electrical panels, HVAC components, elevator parts, and industrial enclosures.
Trusted by Manufacturers Worldwide
Across industries big and small, companies count on our bending technology to keep their production moving smoothly. From metal furniture makers to enclosure builders and high-precision component manufacturers, our systems help teams produce consistent parts with less effort and more confidence.
TRANSFORM YOUR BENDING PERFORMANCE NOW
Step into the future of sheet-metal bending with ANYBEND - an intelligent bending solution engineered for speed, accuracy, and automation excellence. Designed to meet the demands of modern manufacturing, ANYBEND delivers consistent precision, faster cycle times, and flawless repeatability across every bend.
98%
Bending Accuracy Consistency
450+
Global Clients Using ANYBEND Solutions
1500+
Industrial Projects Commissioned
24/7
Technical Support Availability
